Introducing the Traver Force 100-watt monocrystalline solar panel, meticulously engineered with leading 10-busbar technology. This improved design ensures not only higher efficiency but also an extended service life. Featuring grade A+ 182mm premium solar cells, this solar panel offers an impressive cell efficiency of up to 25%, surpassing conventional counterparts. By making the switch from conventional 5-busbar solar panels, you can revel in improved performance, reduced crack risks, and lower operating temperatures. Upgrade to the Traver Force panel for a solar power solution that is both more efficient and reliable.
Read More
Read More
Read More
Read More
Read More
| General | |
| Model | TSP100D-30 |
| UPC Number | |
| Electrical | |
| Max Power at STC | 100W |
| Open Circuit Voltage | 20.5 V |
| Short Circuit Current | 6.03 A |
| Optimum Operating Voltage | 17.6 V |
| Optimum Operating Current | 5.68 A |
| Cell Efficiency | Up to 25% |
| Maximum System Voltage | 600 VDC UL |
| Maximum Series Fuse Rating | 15 A |
| Mechanical | |
| Cell Type | Monocrystalline |
| Dimensions | 38.1 x 22.6 x 1.2 in/970 x 576 x 30 mm |
| Weight | 13 lbs/5.9 kg |
| Front Glass | Low Iron-Tempered Glass |
| Frame | Anti-Corrosion Aluminium Alloy |
| Connectors | MC4 Solar Connectors |
| Fire Rating | Class C |
| Thermal Characteristics | |
| Temperature Coefficient of Pmax | -0.37%/ºC |
| Temperature Coefficient of Voc | -0.28%/ºC |
| Temperature Coefficient of Isc | 0.048%/ºC |
| MC4 Solar Connectors | |
| IP Rating | IP 68 |
| Junction Box | |
| IP Rating | IP 65 |
| Output Cables | 14 AWG (1.97 ft length) |
| Accessories | |
| Junction Box (on the back sheet) | |
| MC4 Solar Connectors (on the back sheet) | |
| Warranty | |
| Material and Workmanship Warranty | 5 Year |
| Performance Warranty | 5 year / 95% output, 10 year / 90% output, 25 year / 80% output warranty |
